Basic data
- Series 8
- Type of scanning system Against object
-
Optical data
- Light source Laser, Red
- Laser class 2, IEC/EN 60825-1:2007
- Light spot size [at sensor distance] 2 mm x 6 mm
-
Measurement data
- Measurement range 20 … 500 mm
- Resolution 0.1 … 0.5 mm
- Accuracy, short range 2 %
- Accuracy, distant range 4 %
- Reference value, accuracy Measurement distance
- Repeatability, short range 1 %
- Repeatability, distant range 3 %
- Reference value repeatability Measurement distance
- Measurement time 2 … 7 ms
- Referencing No
- Black/white behavior 1.5 %
- Optical distance measurement principle Triangulation
-
Electrical data
-
Performance data
- Supply voltage UB 18 … 30 V, DC
-
Outputs
- Number of analog outputs 1 Piece(s)
- Number of digital switching outputs 2 Piece(s)
-
Analog output 1
- Type Voltage
-
Switching output 1
- Switching element Transistor, Push-pull
-
Switching output 2
- Switching element Transistor, Push-pull
-
-
Connection
-
Connection 1
- Type of connection Connector, Turning, 90°
- Thread size M12
- Material Metal
- No. of pins 5 -pin
-
-
Mechanical data
- Dimension (W x H x L) 15 mm x 48 mm x 38 mm
- Housing material Metal
- Metal housing Diecast zinc
- Lens cover material Glass
- Net weight 70 g
