| Sensor/ detection principle | Photoelectric proximity sensor, Background suppression |
| Dimensions (W x H x D) | 15 mm x 49 mm x 41.5 mm |
| Housing design (light emission) | Rectangular |
| Sensing range max. | 30 mm … 200 mm 1) |
| Focus | 100 mm |
| Type of light | Visible red light |
| Light source | Laser 2) |
| Light spot size (distance) | Ø 0.2 mm (100 mm) |
| Wave length | 650 nm |
| Laser class | 2 (EN 60825-1:2014, IEC 60825-1:2007) 3) |
| Adjustment | Potentiometer |
| Special applications | Detecting small objects, Detection of objects moving at high speeds |
| Supply voltage | 10 V DC … 30 V DC 1) |
| Ripple | < 5 Vpp 2) |
| Current consumption | 55 mA 3) |
| Switching output | PNP 4)
NPN 5) |
| Switching mode | Light switching 4)
Dark switching 5) |
- 1) Object with 18% remission (based on standard white DIN 5033).
- 2) Average service life: 50,000 h at TU = +25 °C.
- 3) Pulse length 4 µs, max. pulse power < 5,0 mW.
